1. Design Concept
This LED street lamp integrates ancient oriental archery elements with state-of-the-art LED technology, reimagining functional lighting as a piece of cultural art. The bow-and-arrow-inspired structure pays homage to traditional heritage, while the sleek lines and modern LED modules showcase innovative design. It is not only an energy-efficient lighting solution but a visually striking installation that blends historical aesthetics with contemporary engineering, making it a standout piece in urban landscapes.
2. Name
Archery Heritage LED Street Lamp
3. Core Selling Points
- Cultural Resonance in Southeast Asia: The archery-inspired design connects with regional historical narratives (e.g., ancient warfare, traditional sports heritage), making it ideal for cultural parks, historical districts, and tourist attractions.
- High-Performance LED Efficiency: Equipped with premium LED chips, it delivers bright, uniform illumination while minimizing energy consumption and maintenance costs, meeting sustainability goals and reducing operational expenses.
- Landmark-Level Aesthetic Appeal: It serves as both a practical light source and a distinctive cultural landmark, enhancing the visual identity of streets, plazas, and commercial zones, thereby boosting the area’s attractiveness and foot traffic.
4. Specification Sheet (English Version)
| Item | Specification |
|---|---|
| Product Name | Archery Heritage LED Street Lamp |
| Material | Lamp Post: High-Strength Aluminum Alloy; Decorative Parts: Corrosion-Resistant Metal; Lamp Cover: Tempered Glass |
| Dimensions | – Total Height: 10m (Customizable)- Lamp Post Width: 200mm (Vertical Beam); Bow Arm Length: 1500mm- Billboard Size: 600mm (W) × 1000mm (H) Each |
| LED Configuration | – Light Source: High-Efficiency SMD LED Chips- Color Temperature: 3000K (Warm White, Customizable)- Luminous Flux: 30,000lm (Total, Adjustable)- CRI (Color Rendering Index): ≥85 |
| Electrical Specs | – Voltage: AC 220V/50Hz (Suitable for Southeast Asia & Middle East; Custom Voltage Available)- Power Consumption: 200W- Power Factor: ≥0.92 |
| Protection & Durability | – IP Rating: IP65 (Dust-Tight & Water-Resistant)- Corrosion Resistance: Class C5- Lifespan: ≥50,000 Hours |
| Installation | – Foundation: Reinforced Concrete Foundation with Anchor Bolts (Installation Guide Included)- Mounting: Compliant with Local Urban Infrastructure Standards |
| Additional Features | – Decorative Elements: Oriental Archery-Themed Patterns- Billboard Slots: 2 Slots for Advertising/Cultural Messaging- Warranty: 3 Years (Parts & Labor) |
