LuminaGuard LED Street Lamp

  1. Design Concept
    This LED street lamp embodies the “minimalist aesthetics meets functional durability” design philosophy, tailored for the diverse urban and suburban landscapes of Southeast Asia and the Middle East. Its streamlined lamp body, crafted with high-purity aluminum alloy, eliminates redundant decorations while optimizing heat dissipation—critical for regions with year-round high temperatures (up to 45°C). The curved light cover, made of impact-resistant tempered glass, not only enhances the lamp’s modern silhouette but also ensures uniform light distribution, reducing glare for both pedestrians and drivers. The integrated LED module, paired with a smart dimming chip, balances brightness (up to 150lm/W) and energy efficiency, reflecting a design commitment to “visual elegance without compromising practicality.”
  2. Product Name
    LuminaGuard LED Street Lamp
  3. Core Selling Points
  • Extreme Environmental Adaptability: Engineered to withstand Southeast Asia’s high humidity (80-95% annual average) and the Middle East’s sandstorms, with IP66 waterproof/dustproof rating and 1000-hour salt spray resistance. Equipped with 6kV surge protection to cope with frequent thunderstorms in Southeast Asia, ensuring stable operation in harsh conditions .
  • Intelligent Energy-Saving & Low Maintenance: Adopts adaptive dimming technology (automatically reduces brightness by 30% during low-traffic hours) and a 50,000-hour LED lifespan—8 times longer than traditional sodium lamps. Reduces electricity costs by 60% annually and maintenance frequency to once every 5 years, ideal for Southeast Asia’s municipal projects with tight budgets .
  • Localized Compliance & Supply Chain Advantage: Meets SASO 2927:2019 (Middle East) and ASEAN LED lighting standards, with EER energy efficiency certification and CE marking. Leverages Vietnam-based production bases to cut import tariffs by 0-5% and shorten delivery time to Southeast Asian ports to 3-7 days .
  1. LED Street Lamp Specification Sheet

LuminaGuard LED Street Lamp – Specification Sheet

1. Basic Information

ItemDetails
Model No.LG-SL-40W/60W/80W/100W
Product NameLuminaGuard LED Street Lamp
ApplicationUrban roads, suburban streets, industrial parks, residential areas
CertificationSASO 2927:2019, IEC 60598, CE, RoHS, ISO9001

2. Electrical Parameters

Parameter40W Model60W Model80W Model100W Model
Input Voltage100-277V AC, 50/60Hz (wide voltage for Southeast Asia/Middle East)
Power Factor (PF)≥0.95≥0.95≥0.95≥0.95
Total Harmonic Distortion (THD)≤10%≤10%≤10%≤10%
Surge Protection6kV (line to line)
Power Consumption40W±5%60W±5%80W±5%100W±5%

3. Optical Parameters

ParameterSpecifications
LED Chip BrandCree/XPG3 (high stability for high temperature)
Luminous Efficacy≥120lm/W (meets SASO 2927:2019 requirement)
Luminous Flux4800lm±5%7200lm±5%9600lm±5%12000lm±5%
Color Temperature3000K (warm white) / 4000K (natural white) / 6000K (cool white)
Color Rendering Index (CRI)≥70 (high color 还原 for public safety)
Beam Angle120°×60° (asymmetric distribution for road lighting)
Glare Rating (UGR)≤19

4. Mechanical & Environmental Parameters

ParameterSpecifications
Housing MaterialDie-cast aluminum alloy (ADC12) + tempered glass
Surface TreatmentElectrostatic powder coating (anti-UV, anti-corrosion)
Protection RatingIP66 (waterproof/dustproof)
Salt Spray Resistance≥1000 hours (ASTM B117 standard)
Operating Temperature-20°C ~ +55°C (adaptive to Southeast Asia/Middle East climate)
Storage Temperature-40°C ~ +85°C
Wind Resistance≤12 级 (32.7m/s)
Weight5.2kg (40W) / 6.8kg (60W) / 8.5kg (80W) / 10.3kg (100W)

5. Control & Smart Functions

  • Dimming Mode: 0-10V DC dimming / DALI dimming / Photocell sensor (automatic on/off based on ambient light)
  • Smart Monitoring: Optional NB-IoT/GPRS module for remote voltage, current, and fault monitoring
  • Motion Sensor: Optional PIR sensor (adjusts brightness to 100% when motion detected, 30% otherwise)

6. Installation & Warranty

  • Installation Type: Bracket mounting (pole diameter: 60-114mm)
  • Cable Entry: PG16 waterproof connector
  • Warranty Period: 5 years (free replacement for quality defects)
  • Installation Accessories: Mounting bracket, stainless steel bolts, waterproof gasket

7. Packaging Details

  • Package Type: Carton + foam cushioning
  • Package Size (per unit): 450×320×210mm (40W) / 520×380×240mm (100W)
  • Quantity per Container: 200 units (40W, 20ft container) / 150 units (100W, 20ft container)
